Graphics card comparison
Radeon HD 8470D IGP vs GeForce GT 720
AMD
Radeon HD 8470D IGP
0 Mb System Shared
Released 29 Jul 2013
DESKTOP
VS
Nvidia
GeForce GT 720
1024 Mb DDR3
Released 29 Sep 2014
DESKTOP
Summary
Reasons to consider the Radeon HD 8470D IGP
- Based on an outdated architecture (ATI TeraScale), there are no performance optimizations for current games and applications
Reasons to consider the GeForce GT 720
- 46 watts lower power draw. This might be a strong point if your current power supply is not enough to handle the Radeon HD 8470D IGP .
- This is a much newer product, it might have better long term support.
- Supports PhysX
- Supports G-Sync
- Supports ShadowPlay (allows game streaming/recording with minimum performance penalty)
- Based on an outdated architecture (Nvidia Kepler), there are less performance optimizations for current games and applications
Our verdict
No clear winner declared
We have no data to declare a winner at this time.
Specifications
Core configuration
| Radeon HD 8470D IGP | GeForce GT 720 |
|---|
| GPU Name | Scrapper () | GK208 () |
| Fab Process | 32 nm | 28 nm |
| Die Size | 246 mm² | 87 mm² |
| Transistors | 1,303 million | unknown |
| Shaders | 192 | 192 |
| Compute Units | 3 | 1 |
| Core clock | 800 MHz | 797 MHz |
| ROPs | 4 | 8 |
| TMUs | 12 | 16 |
Memory configuration
| Radeon HD 8470D IGP | GeForce GT 720 |
|---|
| Memory Type | System Shared | DDR3 |
| Bus Width | System Shared | 64 bit |
| Memory Speed | System Shared | 800 MHz
1600 MHz effective |
| Memory Size | 0 Mb | 1024 Mb |
Additional details
| Radeon HD 8470D IGP | GeForce GT 720 |
|---|
| TDP | 65 watts | 19 watts |
| Release Date | 29 Jul 2013 | 29 Sep 2014 |
Raw performance comparison
Pixel Rate
- Radeon HD 8470D IGP3.20 GP/s
- GeForce GT 7203.19 GP/s
GigaPixels - higher is better
Texel Rate
- Radeon HD 8470D IGP9.60 GT/s
- GeForce GT 72012.75 GT/s
GigaTexels - higher is better
Memory bandwidth
- Radeon HD 8470D IGP0.00 GB/s
- GeForce GT 72012.80 GB/s
GB/s - higher is better
Single precision performance
- Radeon HD 8470D IGP307.20 GFLOPs
- GeForce GT 720306.05 GFLOPs
GFLOPs - higher is better
