Graphics card comparison
HD Graphics 4600 (Haswell GT2) vs Radeon HD 5570
Intel
HD Graphics 4600 (Haswell GT2)
0 Mb System Shared
Released 3 Jun 2013
DESKTOP
VS
AMD
Radeon HD 5570
1024 Mb GDDR3
Released 11 Oct 2011
DESKTOP
Summary
Reasons to consider the HD Graphics 4600 (Haswell GT2)
- This is a much newer product, it might have better long term support.
Reasons to consider the Radeon HD 5570
- Based on an outdated architecture (ATI TeraScale), there are no performance optimizations for current games and applications
Our verdict
No clear winner declared
We have no data to declare a winner at this time.
Specifications
Core configuration
| HD Graphics 4600 (Haswell GT2) | Radeon HD 5570 |
|---|
| GPU Name | Haswell GT2 () | Turks (Turks LE) |
| Fab Process | 22 nm | 40 nm |
| Die Size | 177 mm² | 118 mm² |
| Transistors | 392 million | 716 million |
| Shaders | 20 | 320 |
| Compute Units | 0 | 4 |
| Core clock | 400 MHz | 650 MHz |
| ROPs | 2 | 4 |
| TMUs | 4 | 16 |
Memory configuration
| HD Graphics 4600 (Haswell GT2) | Radeon HD 5570 |
|---|
| Memory Type | System Shared | GDDR3 |
| Bus Width | System Shared | 128 bit |
| Memory Speed | System Shared | 500 MHz
1000 MHz effective |
| Memory Size | 0 Mb | 1024 Mb |
Additional details
| HD Graphics 4600 (Haswell GT2) | Radeon HD 5570 |
|---|
| TDP | 45 watts | 39 watts |
| Release Date | 3 Jun 2013 | 11 Oct 2011 |
Raw performance comparison
Pixel Rate
- HD Graphics 4600 (Haswell GT2)5.40 GP/s
- Radeon HD 55702.60 GP/s
GigaPixels - higher is better
Texel Rate
- HD Graphics 4600 (Haswell GT2)10.80 GT/s
- Radeon HD 557010.40 GT/s
GigaTexels - higher is better
Memory bandwidth
- HD Graphics 4600 (Haswell GT2)0.00 GB/s
- Radeon HD 557016.00 GB/s
GB/s - higher is better
Single precision performance
- HD Graphics 4600 (Haswell GT2)432.00 GFLOPs
- Radeon HD 5570416.00 GFLOPs
GFLOPs - higher is better
