Graphics card comparison
GeForce RTX 3070 Ti 16 GB vs GeForce RTX 3070 Ti
Nvidia
GeForce RTX 3070 Ti 16 GB
16384 Mb GDDR6X
Released UNRELEASED
DESKTOP
VS
Nvidia
GeForce RTX 3070 Ti
16384 Mb GDDR6
Released UNRELEASED
DESKTOP
Summary
Reasons to consider the GeForce RTX 3070 Ti 16 GB
Reasons to consider the GeForce RTX 3070 Ti
- 90 watts lower power draw. This might be a strong point if your current power supply is not enough to handle the GeForce RTX 3070 Ti 16 GB .
- Supports PhysX
- Supports G-Sync
- Supports ShadowPlay (allows game streaming/recording with minimum performance penalty)
- Supports Direct3D 12 Async Compute
- Supports DirectX Raytracing (DXR)
- Supports Deep Learning Super-Sampling (DLSS)
Our verdict
No clear winner declared
We have no data to declare a winner at this time.
Specifications
Core configuration
| GeForce RTX 3070 Ti 16 GB | GeForce RTX 3070 Ti |
|---|
| GPU Name | GA104 (GA104-401-A1) | GA104 () |
| Fab Process | 8 nm | 8 nm |
| Die Size | 392 mm² | 392 mm² |
| Transistors | 17,400 million | 17,400 million |
| Shaders | 6144 | 6144 |
| Tensor Cores | 192 | none |
| Raytracing Cores | 48 | none |
| Compute Units | 48 | 48 |
| Core clock | 1575 MHz | 1500 MHz |
| ROPs | 96 | 96 |
| TMUs | 192 | 192 |
Memory configuration
| GeForce RTX 3070 Ti 16 GB | GeForce RTX 3070 Ti |
|---|
| Memory Type | GDDR6X | GDDR6 |
| Bus Width | 256 bit | 256 bit |
| Memory Speed | 1188 MHz
19 Gbps effective | 1750 MHz
14 Gbps effective |
| Memory Size | 16384 Mb | 16384 Mb |
Additional details
| GeForce RTX 3070 Ti 16 GB | GeForce RTX 3070 Ti |
|---|
| TDP | 290 watts | 200 watts |
| Release Date | UNRELEASED | UNRELEASED |
Raw performance comparison
Pixel Rate
- GeForce RTX 3070 Ti 16 GB169.90 GP/s
- GeForce RTX 3070 Ti165.60 GP/s
GigaPixels - higher is better
Texel Rate
- GeForce RTX 3070 Ti 16 GB339.80 GT/s
- GeForce RTX 3070 Ti331.20 GT/s
GigaTexels - higher is better
Memory bandwidth
- GeForce RTX 3070 Ti 16 GB608.30 GB/s
- GeForce RTX 3070 Ti448.00 GB/s
GB/s - higher is better
Single precision performance
- GeForce RTX 3070 Ti 16 GB21750.00 GFLOPs
- GeForce RTX 3070 Ti21200.00 GFLOPs
GFLOPs - higher is better
